Bevelled edges - Smooth

PRODUCT DESCRIPTION
Edges designed especially to help the traffic of trolleys without jerking. Especially suited for hospitals.

Find out more
CHOICE OF CRITERIA

Detailed description

>> Desctexteproduit :
Edges designed especially to help the traffic of trolleys without jerking. Especially suited for hospitals.

References -Technical data

refArticle	Material	Length	Width	Type 1	Max. load	designationComplete
2821	Alu silver	3.00 m	60 mm	Adhesive on both sides	Admissible weight : 19 kg/cm²	EXPANSION PROFILE BEVELLED SILVER 60MM 3M ADH
2820	Alu silver	3.00 m	80 mm	Adhesive on both sides	Admissible weight : 56,9 kg/cm²	EXPANSION PROFILE BEVELLED SILVER 80MM 3M ADH
2814	Alu silver	3.00 m	100 mm	Adhesive on both sides	Admissible weight : 74,4 kg/cm²	EXPANSION PROFILE ALU SILVER 100MM 3M ADH
2815	Alu silver	3.00 m	100 mm	1 side adhesive, 1 side drilled	Admissible weight : 74.7 kg/cm²	EXPANSION PROFILE ALU SILVER 100MM 3M DRILLED-ADH
2815	Alu silver	3.00 m	100 mm	1 side adhesive, 1 side drilled	Admissible weight : 74.7 kg/cm²	EXPANSION PROFILE ALU SILVER 100MM 3M DRILLED-ADH
2822	Alu silver	3.00 m	120 mm	Adhesive on both sides	Admissible weight : 66,4 kg/cm²	EXPANSION PROFILE BEVELLED SILVER 120MM 3M ADH
2824	Alu silver	3.00 m	80 mm	Adhesive on both sides	Admissible weight : 61.5 kg/cm²	EXPANSION PROFILE ALU SILVER BEVEL EDGE 80MM - 3M
2819	Alu silver	3.00 m	150 mm	Adhesive on both sides	Admissible weight : 54.2 kg/cm²	EXPANSION PROFILE HEAVY LOAD ALU SILV 150MM 3M ADH

Document downloads

Réf. 2821	Technical sheets	Dowload PDF
Réf. 2820	Technical sheets	Dowload PDF
Réf. 2814	Technical sheets	Dowload PDF
Réf. 2815	Technical sheets	Dowload PDF
Réf. 2815	Technical sheets	Dowload PDF
Réf. 2822	Technical sheets	Dowload PDF
Réf. 2824	Technical sheets	Dowload PDF
Réf. 2819	Technical sheets	Dowload PDF
